MMM MIDM 25032424
MMM 25032424 Hydraulic Elbow, 1-7/8-12 x 1-1/2 in Nominal, 37 deg SAE Male JIC Flare, Steel
Invoice description:
Elbow Hc 1-7/8-12x1-1/2i N 45deg Midland Industries 25032424 Hydraulic Elbow, 1-7/8-12 X 1-1/2 In Nominal, 37 Deg Sae Male Jic Flare, Steel
Factory Order
MMM Hydraulic Elbow, 1-7/8-12 x 1-1/2 in Nominal, 37 deg SAE Male JIC Flare, 45 deg, 2000 psi, Steel
Features
- Flared fitting or tube assembly is tightened against the cone with a swivel nut
- By forcing the flare against the cone during the torquing process, the nose cone is slightly deformed and meshes to create a metal to metal seal between the flare and the cone
Specifications
Nominal Size 1-7/8-12 x 1-1/2 in
End Style 37 deg SAE Male JIC Flare
Angle 45 deg
Additional Information
Standards/ApprovalSAE 070302|MS 51508
Country of OriginUS
