MMM MIDM 12026
MMM 12026 Union Internal Connector, 3/8 in Nominal, Female Inverted Flare, CA360 Brass, Import
Invoice description:
Connector Intl Un 3/8in 0.032in Wall Midland Industries 12026 Union Internal Connector, 3/8 In Nominal, Female Inverted Flare, Ca360 Brass, Domestic
Factory Order
MMM Union Internal Connector, Fitting/Connector Type: Connector, 3/8 in Nominal, Female Inverted Flare, 0.032 in Thickness, 3/4 in Hex, 1000 psi, -65 to 250 deg F, CA360 Brass, 0.8 in L, Import
Features
- Excellent vibration resistance
- Very low cost and reusable
- Short nut affords very close tube bends
- Seats and threads are internal and protected
- /- 0.03 tolerance on all dimensions
- Compact, excellent vibration life, short nut affords very close tube bends, steel or brass tube nut
Specifications
ApplicationHydraulic Brake, Power Steering, Fuel Lines and Transmission Cooler Lines, LP and Natural Gas, Copper, Brass, Aluminum and Steel Hydraulic Tubing That Can Be Flared
Fitting/Connector Ty Connector
Nominal Size 3/8 in
End Style Female Inverted Flare
Thickness 0.032 in
Hex Size 3/4 in
Pressure Rating 1000 psi
Additional Information
Standards/ApprovalASA|ASME|MS and SAE 040101
Country of OriginUS
