GARR GARR 23067
GARR 23067 263MA Center Cutting Square End High Performance End Mill, 5/8 in Dia Cutter, 1-1/4 in Length of Cut, 3 Flutes, 5/8 in Dia Shank, 3-1/2 in OAL, TiALN Coated
Invoice description:
Em 5/8x1-1/4locx5/8x 3-1/2 3fl Tialn Hp
Factory Order
GARR High Performance End Mill, Center Cutting Square End, Series: 263MA, 5/8 in Diameter Cutter, 3-1/2 in Overall Length, 1-1/4 in Length of Cut, 3 Flutes, Spiral Flute, 5/8 in Shank Diameter, Right Hand Cutting Direction, 60 deg Helix Angle, 2-1/4 in Shank Length, Solid Submicron Carbide, TiALN Coated
Features
- High performance profiling of steels, stainless steel and high temperature alloys
- Rigid work holding, machine stability and part integrity are critical
- Modified end gash - will not cut square corner
- Up to 25% faster than uncoated
Specifications
ApplicationDry or Semi-Dry Machining
Cutter Diameter5/8 in
Cutting DirectionRight Hand
FinishTiALN Coated
Flute TypeSpiral
Helix Angle60 deg
Length of Cut1-1/4 in
MaterialSolid Submicron Carbide
Number of Flutes3
Overall Length3-1/2 in
Series263MA
Shank Diameter5/8 in
Shank Length2-1/4 in
TypeCenter Cutting Square End
Additional Information
Country of OriginUS
